Rail Assembly Process Simplified

Oct. 10, 2006
Selecting, planning and ordering custom-designed rail assemblies is easier with RailDesigner 4.0 software. Design, draw, e-mail your vendor for quotes and place your order using this software.
New features include a “RailDesigner Assistant” that will navigate you through every process; improved database capabilities; ability to create a subassembly as one part; and enclosure design software. RailDesigner 4.0 includes standard windows functions, simple menu options, straightforward graphics and user-friendly interface. A navigation window displays an overview of all utilized terminal rails and an export/import interface provides direct access to drawing files.  Products are accessed with an intelligent database search function and individual product libraries. Parts lists, detailed descriptions of the terminal rail and notes on correctly assembling the rail assembly are automatically generated. Weidmullerwww.weidmuller.comPhone:  804.794.2877
