Siemens: Controller for motion-control tasks

Siemens has matched its new Simatic S7-1500 T-CPU controller with its Sinamics servo drive system, simplifying complex motion control tasks.

Jan 24th, 2017

Controller for motion-control tasks

Controller for motion-control tasks

The matched controller and drive system are integrated into Siemens TIA Portal engineering framework, making them suitable for electronic gearing, camming and other advanced motion control applications. Additionally, the new controller is suitable for safety applications, eliminating the need for multiple CPUs for standard, safety and motion control automation tasks.

An easy-to-use integrated Cam Editor simplifies configuration, optimization and diagnostics of variable, position-dependent transmission ratios between leading and following axes. The cams can be changed or readjusted for product changes, even while the machine is running.

Siemens Digital Factory (DF) offers a comprehensive portfolio of seamlessly integrated hardware, software and technology-based services in order to support manufacturing companies worldwide in enhancing the flexibility and efficiency of their manufacturing processes and reducing the time to market of their products.
