In its standard design, this CPU is equipped with a 100Mbps Fast Ethernet interface that can be used either as the online interface or for networking. A CAN and RS232 interface is integrated as well. Because the CPU’s design and dimensions correspond to the X20 system, I/O modules attach seamlessly to the right side of the CPU, saving space in the switching cabinet. Rail mechanics allow the complete system to be mounted on the rail like a rack and taken down just as easily, says the vendor. An extended CPU design is also available, equipped with a 25mm-wide slot for X20 interface modules. This allows the entire range of additional interface modules such as Profibus, DP, CANopen and DeviceNet to be used.
B&R Industrial Automation Corp.
