I/O Module

June 1, 2006
Wago has added motion control capability to its I/O System family of products with the new 750-670 I/O module. It provides stepper motor and servo drive control in a compact 12mm-W package, and supports 2 pulse output patterns, step/direction, or implemental encoder.

Communication with stepper or servo is established via RS-422 interface and controlled by a variable output frequency. 2 digital inputs may be configured to support common motion signals. The module is compatible with all other 750 Series modules.
