The SNAP-UDC-HDB-G4 breakout board from Opto 22 provides 32-point SNAP digital I/O modules with up to 3 amps current switching, fused outputs, and isolated inputs, while the compact SNAP-UDC-HDB board saves panel space and simplifies field wiring.

Aw 93704 1602np Opto22

With the SNAP-UDC-HDB-G4 breakout board, OEMs, machine builders, and automation professionals can connect 32-point SNAP digital I/O modules to higher loads with fused outputs and isolated inputs, while the space-saving SNAP-UDC-HDB breakout board provides convenient spring-clamp connectors for up to 32 field devices, all in a small footprint. The SNAP-UDC-HDB-G4 holds up to 32 G4 digital I/O modules, which can provide up to 3 amps current switching or sensing per point, fused outputs, isolated inputs, and per-point LED indicators, depending on the G4 modules selected. For example, using G4 digital output modules on the breakout board lets a SNAP-ODC-32-SNK 32-point module switch up to 12 times its regular current load of 0.25 amps. Spring-clamp connectors secure field wiring and reduce installation time. The SNAP-UDC-HDB breakout board consolidates wiring for a 32-point SNAP digital I/O module into a compact 4.0 in. x 3.3 in. (101 mm x 83 mm) board, which simplifies installation, reduces labor costs, and saves space inside enclosures and machines. The board includes convenient per-point LED indicators that show point status and are useful for troubleshooting and maintenance. Easy-to-use spring-clamp connectors hold field wiring securely in place.
