Schneeberger Product News

New Schneeberger Monorail Application Catalog

This content was submitted directly to this website by the supplier.

Jul 9th, 2014

New Schneeberger Monorail Application Catalog

Schneeberger Linear Technology announces a new application catalog for ball and roller monorail linear guides and the AMS integrated measuring systems.

The application catalog provides engineering and technical data for all Schneeberger monorail products along with design criteria, drive systems, AMS encoder systems, (including absolute and incremental encoders), application examples and maintenance.

>> To download a PDF version, click here

New Miniscale Plus 0.1 um encoder

Schneeberger Linear Technology announces the new Miniscale Plus optical encoder system now with resolutions to 0.1 micron. Miniscale Plus is available as an option for all Minirail products from sizes 7 to 42 and short to extra long carriages and rails to 1 meter in length.

aximize your system accuracy by taking the measurement at the payload. Compared to an external encoder, the smaller envelope needed for mounting the Miniscale Plus will increase the available real estate inside your machine. In addition the Miniscale Plus does not require set up or adjustment saving valuable installation time.

>> To view the specification page for the 1.0 micron Miniscale, click here
